HOURLY VALUES OF EQUATORIAL DST INDEX (FINAL)         WDC-C2 FOR GEOMAGNETISM, KYOTO UNIVERSITY

      MAY 1996
                                                  Unit=nT, Time=number of the hour in UT day
      1   2   3   4   5   6   7   8    9  10  11  12  13  14  15  16   17  18  19  20  21  22  23  24
DAY
 1    2   6   4  -1  -5  -5  -9 -13  -12  -7  -3   0   0  -6  -9  -9   -9  -8  -8  -7  -3   2   3   4
 2    4   4   9  11  10   9   8   7    2  -6  -7  -3   2   3   5   5    2   2   1   1   1   2  -1  -4
 3   -2   3   6   2  -4  -3   1   1    0   2   6  10  13  10   1  -1    0   4   8   9   9  12   8   4
 4   -3  -7  -9 -12 -10 -10  -5  -1    0   3   6  10   5   7  11   7    2  -5  -7  -8  -7  -8 -13 -16
 5  -13 -14 -10 -10 -11  -8 -10 -11   -7  -5  -7  -9 -10  -8 -10  -9   -9 -10 -11 -11  -9  -8  -9 -12

 6  -12 -10 -10 -10 -12 -14 -16 -15  -16 -12  -7  -5  -4  -5  -6  -4   -5  -5  -5  -2   1   7   8   9
 7    8   4   8   9   8   7   9  11   11   9   8   2   1   2   2   3    5   5   5   6   4  -2  -3  -2
 8   -2  -4 -10 -15 -19 -23 -19 -16  -13 -14 -12  -8  -4  -4  -3  -1    1   0  -2  -3  -1  -1  -2  -3
 9   -2   1   0  -3  -3  -4  -2   0    3   3   5   7   6   2  -3  -3    0   2   1   3   2   0  -1  -6
10   -9 -10  -8  -8  -7  -6  -2   0   -1  -3  -6  -5  -6  -6  -6  -2    2   2   1  -1  -3  -2  -2  -4

11   -3  -1   1  -2  -7 -10  -8  -4   -2  -2  -1   0  -1  -4  -1   1    5   9  11  10   9   9   9   6
12    7   6   5   3   3   2   2   4    2   2   2   2   0   1   3   7   12  11  11  12  10   6   4   6
13    9   3  -2  -1  -8 -20 -19 -17  -20 -14  -9  -2  -6  -5  -1  -1   -4  -3   1   1  -3 -10 -15 -11
14  -11 -10 -10 -15 -12 -16 -16 -15  -13 -14 -15 -13 -12 -13 -16 -14  -11  -8 -12 -10 -14 -23 -29 -24
15  -20 -20 -21 -21 -18 -13  -9 -18  -12 -10 -10 -14 -18 -20 -18 -12   -5  -2  -7 -14 -11 -11 -14 -18

16  -19 -16 -12 -15 -18 -18 -14 -12  -11 -10 -11 -14 -16 -18 -17 -15  -12 -10 -10 -14 -17 -12  -9  -4
17   -3  -3  -2  -2  -2  -9 -17 -18  -24 -25 -26 -20 -18 -16 -19 -21  -19 -20 -20 -23 -19 -19 -21 -21
18  -20 -18 -15 -13 -10  -8  -6  -7  -10 -14 -12 -12 -13 -12 -10  -9   -7  -5  -4  -3  -2  -1  -2  -2
19   -2   1   0   0   1   2   6  10    6   5   3   0  -4  -4  -2   1    3   2  -3  -1  -3  -2  -3  -8
20  -16 -18 -21 -16 -14 -12 -13 -10   -9 -11 -12 -10  -8 -10 -12 -11   -7  -7  -4  -2  -3 -15 -19 -19

21  -14 -16 -20 -17 -19 -18 -15 -10  -13 -10  -8  -7  -7  -8  -3  -4   -8  -9  -7  -9 -13 -13 -13 -15
22  -14  -9  -9 -10 -10  -8  -6  -3   -3  -3  -2  -3  -2  -3  -5  -5   -4  -3  -6  -9 -10 -11  -5  -4
23   -6  -4   0  -5  -4   2  -1  -1    1   3   3   4   5   7   8   8    9   7   6   7  10   9   9  10
24   10   9   9  11  13  12   8   6   11   9   6  10   9   7   3   2    0   0   2   1   2   1   2   4
25    3   4   6   5  -2   1   2   2    0   0   0   0   0   1   2   3    1   1  -1   0   3   3  -3  -9

26   -8 -11 -12 -13  -9 -12 -13  -9   -8  -9  -7  -6  -5  -8  -9  -7   -5  -3  -2  -2  -2  -6  -8  -7
27   -6  -4  -3  -3  -4  -3  -4  -3   -3  -4 -10 -12  -5   6  12   6   -8 -20 -27 -33 -31 -31 -30 -28
28  -22 -20 -20 -18 -16 -15 -14 -13   -7  -5  -2   1   4   6   6   3    6   8   7   6   7  10  10  12
29   17  19  20  23  24  23  26  26   32  40  32  26  28  22  18  20   16  14  16   9   6   8   6   3
30    6   3   6  -5  -6  -4  -5  -5   -6  -8  -7  -7  -8  -8  -7  -5   -3   3   2   3   3  -3  -7  -5

31    2   4   6   6   5   8  12  13    9  10   9  11  11  11   6   3    0   1   2   4   4  -2  -9  -7
